Advanced Controls
‘Zero & Go!’ Programming allows for easy, repeatable setup time after time. With our setup system you do not need any reference to punch length. It is easily setup through pre-engineered inputs OR at the machine.
Gasbarre’s advanced control systems allow for on-the-fly feedback and adjustments — while holding
position tolerances of +/-0.0003 inches, accuracy of +/-0.00005 inches and force repeatability of +/-0.02 tons on certain CNC presses.
Dynamic Deflection Compensation – The design of our CNC presses provides constant feedback (real-time) from the servos to the controls. This design consideration allows for dynamic compensation as opposed to mechanical stop machines that require offsets in the part recipe.
Powder Transfer and the timing of each platen from filling to transfer to pressing position can be accurately controlled for optimum movement.
Flexibility
Gasbarre’s CNC Presses are ‘true’ CNC presses. The stacked cylinder design gives you full control range over all levels at all times. Full control allows you to adjust to any changes or turnover in business.
Full range use of the designed stroke length of each cylinder. There is no minimum platen movement required to release the mechanical stops and parts can be formed ‘above’ the filling position. Parts can be produced anywhere within the platen movement range. Competitive solid stop designs have a limited adjustment range within the platens movement.
Top Punch Hold Down or Bottom Hold Up Force can be applied to any moving platen in a range from zero to the compacting force load
Serviceability
Fewer moving pieces means less maintenance. The entire base design of the machine is surrounding the platen cylinders, which are stacked within each other. Standard preventive maintenance (can be provided by Gasbarre) will allow your machine to run for decades to come.
Component Feedback/Press Health status comes straight from the press HMI. We are monitoring virtually everything! At a glance you can prevent an issue from arising.
Rigidity
Guidance is core to the machine design. Expanded bearing lengths with the stacked cylinders and tooling guidance allow you to make the highest quality compacted part. This core design concept has proven to give companies an advantage in the short and long term use of Gasbarre presses.
Counterforce is key, and we have it! With the control and weight of the cylinder designs, the Gasbarre press offers counterforce that is far superior to other machines.
When manufacturers select Gasbarre, service comes first. It is the mission of all of our members to ensure that our customers installed equipment is producing product effectively and efficiently. Gasbarre’s commitment to service has been a driving factor of our success.
Gasbarre’s expertise in design, engineering, machining, fabrication, and assembly has been earned over nearly 50 years in business. Our engineers, technicians, and assemblers have extensive experience in mechanical, electrical, and hydraulic applications, providing the breadth and depth of experience to support most any requirement.
The key to our success is based on listening to our customers’ needs and finding solutions to those needs. Most importantly, we continue to work closely with each customer after the sale to ensure all of their needs are met. Gasbarre becomes an extension of our customers’ business, a part of their success
We custom design machinery, machine and fabricate, and assemble. Our engineering staff is equipped with the latest software technology, including 3D modeling. We consistently maintain and upgrade our fabrication, machining, and assembly equipment to ensure that we produce quality, cost effect components and assemblies.
Please give us a call if you would like to learn more about where we are going. Call (814.371.3015) or email ([email protected]) us today!
